FEATURES
QUESTIONS?
Sizes - Weights:
- 31.8x25mm - 316g
- 31.8x 38mm - 313g
- 31.8x50mm 323g
- 35x25mm - 314g
- 35x38mm - 318g
- 35x50mm 324g
Width: 800mm
Clamp Width: 70mm
Backsweep: 10 degrees
Upsweep: 5 degrees
Yes, we offer decals in all of our signature colors made by Ground Keeper Custom.
You can also order custom decal graphics here through our friends at Ground Keeper Custom.
- Clean the desired installation area with an alcohol wipe to remove any dirt, debris, or oil.
- There are three large and three small “PNW” decals. The small ones are located next to the stem and the large ones are closer to the brake levers.
- Slowly peel off the decal from the backing sheet, align the PNW decal with the corresponding PNW graphic found on your handlebars.
- Apply the decals, rubbing each letter for 5-10 seconds each, this will remove any air bubbles under the decal.
- Well dang, look at your fresh colorful PNW Range Handlebars!
Yep! You can trim the Range bar down if you prefer a narrower bar width, we have a guide on the bars for measurement ease. The minimum width the Range Handlebar can be trimmed to is 740mm.
- What happens if I cut them past the minimum cut width?
- Your friends will make fun of you.
- The clamping area for your controls (brakes/shifters/etc) may become too narrow to fit all your doodads.
- Cutting past the minimum cut marks can compromise the bars' structural integrity.
- You will lose stability and leverage if your bars are too narrow, making riding way less fun.
- The engineered ride quality of the bars will be compromised. Our bar is engineered to have more vertical deflection than horizontal, but if the bars are cut past the minimum cut mark, this deflection will be compromised.
For flat/mountain bike bars we recommend our Loam Lever, Range Lever, or Puget 2x lever.
Our Range bars are compatible with 31.8mm or 35mm diameter clamp stems depending on what size bar you choose, and will fit perfectly with our Range or Loam stem in either the 31.8mm or 35mm diameter.
Yes.
19.5mm
Yes.
These bars are great for any type of mountain biking - XC, Trail, Enduro, and even DH. They are also a great bar for a commuter bike or flat bar gravel bike.
No. The factory-installed graphics are under the clear coat so they cannot be removed. However, if you want a new color, you can purchase a decal kit through our website or Ground Keeper Custom.
